Hazardous Area 90 Fixed Adaptor

Hazardous Area 90 Fixed Adaptor

Right Angle Adaptors provide a means of connection where protrusion space is limited. Manufactured from high quality brass and supplied with IP sealing washer as standard.
• An IP rating of IP66 /67/68 is maintained.
• Supplied with sealing washer as standard.

Hazardous: IECEx: Ex db I Mb / Ex eb IIC Mb
ATEX: Ex db IIC Gb, Ex eb IIC Gb, Ex tb IIIC Db
Certification: IECEx CML 16.0059U IEC 60079-0, IEC 60079-1, IEC 60079-7, IEC60079-31
EX CML16ATEX1137U EN 60079-0, EN 60079-1, EN 60079-7, EN 60079-31

IP Protection: IP66 / IP68 (2m)
IP Protection -Tapered Thread: IP65
Temperature Range: -20°C to 95°C
Material: Brass / Nickel Plated Brass

Swipe table
FELBM20M20E M20 x 1.5 17.0 M20 x 1.5 16.0 £999.99 £1,199.99
FELBM25M25E M25 x 1.5 17.0 M25 x 1.5 16.0 £999.99 £1,199.99
FELBM32M32E M32 x 1.5 17.0 M32 x 1.5 16.0 £999.99 £1,199.99
FELBM20N050E M20 x 1.5 17.0 ½" / 0.50 NPT 16.0 £999.99 £1,199.99
FELBM25N075E M25 x 1.5 17.0 ¾" / 0.75 NPT 16.0 £999.99 £1,199.99
FELBM32N100E M32 x 1.5 17.0 1" / 1.00 NPT 16.0 £999.99 £1,199.99
FELBN050M20E ½" / 0.50 NPT 16.0 M20 x 1.5 17.0 £999.99 £1,199.99
FELBN075M25E ¾" / 0.75 NPT 16.0 M25 x 1.5 17.0 £999.99 £1,199.99
FELBN100M32E 1" / 1.00 NPT 16.0 M32 x 1.5 17.0 £999.99 £1,199.99
