SKU: RM63M25E

RM63M25E - M63 Male to M25 Female Exd/Exe Flameproof NP Reducer

SKU: RM63M25E

RM63M25E - M63 Male to M25 Female Exd/Exe Flameproof NP Reducer

Reduces housing entry thread.



  • ISO Metric range.
  • Application; Hazardous Area, Machines, Devices, Housings, Panels
    Equipment Protection Levels: IECEx/INMETRO: Ex db I Mb / Ex eb I Mb / Ex db IIC Gb / Ex eb IIC Gb / Ex ta IIIC Da / Ex nR IIC
    ATEX: I M2 Ex db I Mb / Ex eb I Mb, II 2G 1D Ex db IIC Gb / Ex eb IIC Gb / Ex ta IIIC Da
    Protection: IP66 / IP68 (2m cont.)
    Temperature Range: -60°C to 95°C (-60°C to 160°C with High Temp Gasket)
    Material: Brass or Nickel Plated Brass (Marine Grade)



Quick Links

Nickel Metric
Silver
78.8
70.0
M63 x 1.5
15.0
M25 x 1.5
15.0
6.0

In stock

2

£46.71 Excl VAT
Unit Price: £46.7100 £56.05 Inc VAT
Unit Price: £56.0520

Qty
Minimum Order Qty 1
Increments 1

Product Wishlist & Compare Placeholder

Delivery available from £8.50

Available to select at checkout.



Quick Links




Reduces housing entry thread.



  • ISO Metric range.
  • Application; Hazardous Area, Machines, Devices, Housings, Panels
    Equipment Protection Levels: IECEx/INMETRO: Ex db I Mb / Ex eb I Mb / Ex db IIC Gb / Ex eb IIC Gb / Ex ta IIIC Da / Ex nR IIC
    ATEX: I M2 Ex db I Mb / Ex eb I Mb, II 2G 1D Ex db IIC Gb / Ex eb IIC Gb / Ex ta IIIC Da
    Protection: IP66 / IP68 (2m cont.)
    Temperature Range: -60°C to 95°C (-60°C to 160°C with High Temp Gasket)
    Material: Brass or Nickel Plated Brass (Marine Grade)



Information

Product Type: Nickel Metric

Colour: Silver

A/C: 78.8

A/F: 70.0

Male Thread: M63 x 1.5

Male Thread Length (L1): 15.0

Female Thread: M25 x 1.5

Female Thread Depth (F): 15.0

Hex Depth Min (G): 6.0
