SKU: GRIPLOC-M20L-R

GRIPLOC-M20L-R - M20L IP68 Metric Nylon Cable Gland + O Ring + L/N - Red

SKU: GRIPLOC-M20L-R

GRIPLOC-M20L-R - M20L IP68 Metric Nylon Cable Gland + O Ring + L/N - Red

The GripLoc Nylon Cable Gland is built for secure, long-lasting cable terminations in tough, real-world conditions. Made from durable, flame-retardant PA6 nylon, it offers a watertight IP69K/ IP68 seal that protects against dust, moisture, and movement. This isn't just about sealing, though. The design includes Vibration-Lock technology to stop loosening under heavy use, plus Friction Splines for a solid hold during fitting without over-tightening.

Its Ridge-and-Groove structure improves strain relief and keeps cables stable under tension or flex. With a wide clamping range, it covers multiple cable sizes, which means fewer parts to manage and quicker installs. GripLoc is easy to fit, secure once in place, and works well in control panels, automation systems, or outdoor enclosures.

It's a practical, pro-grade choice for electricians and installers who need reliability and speed without compromise.



Key Features

  • IP69K / IP68 protection against water and dust
  • Vibration-Lock stops loosening from movement
  • Friction Splines give secure, tool-friendly grip
  • Ridge-and-Groove design boosts strain relief
  • Made from flame-retardant PA6 nylon
  • Wide clamping range for flexible sizing
  • GripLoc Seal® - Superior Ingress Protection, mechanical grip and cable retention
  • Supplied Complete with  'O' Ring Seal & Locknuts



Technical Details

Standards: EN 50262
Protection: IP69K / IP68 10 bar (150 PSI)
Temperature Range: -40°C to 100°C (static)
Material (Gland): PA (Nylon) UL 94 V2
Material (Seal): NBR Seal and EPDM O-Ring

Quick Links

Red
M20 x 1.5
10.0
14.0
9.0
37.0
27.0
100
1200

In stock

3932

£3.60 Excl VAT
Unit Price: £0.3600 £4.32 Inc VAT
Unit Price: £0.4320

Qty
Minimum Order Qty 10
Increments 10

Product Wishlist & Compare Placeholder

Delivery available from £8.50

Available to select at checkout.



Quick Links




The GripLoc Nylon Cable Gland is built for secure, long-lasting cable terminations in tough, real-world conditions. Made from durable, flame-retardant PA6 nylon, it offers a watertight IP69K/ IP68 seal that protects against dust, moisture, and movement. This isn't just about sealing, though. The design includes Vibration-Lock technology to stop loosening under heavy use, plus Friction Splines for a solid hold during fitting without over-tightening.

Its Ridge-and-Groove structure improves strain relief and keeps cables stable under tension or flex. With a wide clamping range, it covers multiple cable sizes, which means fewer parts to manage and quicker installs. GripLoc is easy to fit, secure once in place, and works well in control panels, automation systems, or outdoor enclosures.

It's a practical, pro-grade choice for electricians and installers who need reliability and speed without compromise.



Key Features

  • IP69K / IP68 protection against water and dust
  • Vibration-Lock stops loosening from movement
  • Friction Splines give secure, tool-friendly grip
  • Ridge-and-Groove design boosts strain relief
  • Made from flame-retardant PA6 nylon
  • Wide clamping range for flexible sizing
  • GripLoc Seal® - Superior Ingress Protection, mechanical grip and cable retention
  • Supplied Complete with  'O' Ring Seal & Locknuts



Technical Details

Standards: EN 50262
Protection: IP69K / IP68 10 bar (150 PSI)
Temperature Range: -40°C to 100°C (static)
Material (Gland): PA (Nylon) UL 94 V2
Material (Seal): NBR Seal and EPDM O-Ring

Information

Colour: Red

Entry Thread Size: M20 x 1.5

Cable OD Range Min (B): 10.0

Cable OD Range Max (B): 14.0

Entry Thread Length (L1): 9.0

Gland Length (L2): 37.0

A/F: 27.0

Box Qty: 100

Carton Qty: 1200

Accessories

You might also need the following;

Explore Remora’s extensive range of cable gland accessories, including locknuts, earth tags, sealing washers, serrated lock washers, shrouds, earth locknuts, reducers, adaptors, stopping plugs, and breather drain plugs. Everything needed for secure, compliant cable gland installations.

Questions & Answers

Single and double compression cable glands differ in their sealing and clamping mechanisms:

Single Compression Glands: These glands provide compression around the outer sheath of the cable, offering basic sealing and strain relief. They are suitable for indoor/outdoor applications where environmental conditions are controlled.

Double Compression Glands: These glands provide compression at both the outer sheath and the inner bedding layer of the cable. This dual compression offers enhanced sealing and strain relief, making them ideal for outdoor or hazardous environments where additional protection is required.

Yes - Specific types of cable glands are designed for use in hazardous area environments. These glands are constructed to prevent the ingress of flammable gases or dust and are often certified to standards such as ATEX or IECEx, ensuring safety in explosive atmospheres. See CCG Hazardous Area Glands for our full range.

When installing Cable Glands using plain holes and locknuts, the recommended clearance of +0.2 mm above the nominal thread diameter. For example, an M20 gland should be mounted in a 20.2 mm diameter hole. The maximum recommended clearance is +0.7 mm. This ensures a secure fit while allowing easy installation.
