SKU: STPDH0.75NPT

STPDH0.75NPT - 0.75NPT EExd N/Plate Brass Hex Head Stopping Plug

SKU: STPDH0.75NPT

STPDH0.75NPT - 0.75NPT EExd N/Plate Brass Hex Head Stopping Plug

National Pipe Thread (NPT) Hazardous Hex Head Plugs in nickel plated brass (marine grade) are engineered to safely blank unused threaded entries in Hazardous Area, machines, devices, housings, panels and enclosures. Suitable for both temporary and permanent use, these plugs are IECEx and ATEX certified, offering compliance with international standards for safe installation.  National Pipe Thread (NPT) is a tapered thread and is not supplied with sealing washers, P66 protection against dust, dirt and water ingress is achieved. With a temperature rating of -60°C to +95°C, they deliver long lasting performance. Available in the NPT range ½" to 3", these plugs are ideal for industrial, petrochemical, marine and offshore applications.



Key Features

  • Nickel-plated brass (marine grade) for strength and corrosion resistance
  • Hex head design for quick spanner tightening
  • IECEx and ATEX certified for hazardous environments
  • Provides IP66/IP68 ingress protection with sealing gasket
  • Wide operating range: -60°C to +95°C (up to +160°C with high-temp gasket)
  • National Pipe Thread (NPT) range ½" to 3"
  • Suitable for blanking threaded or unthreaded holes (with locknut)





Technical Details

Equipment Protection Levels: IECEx: Ex db I Mb / Ex eb I Mb / Ex db IIC Gb / Ex eb IIC Gb / Ex ta IIIC Da / Ex nR IIC
ATEX: I M2 Ex db I Mb / Ex eb I Mb, II 2G 1D Ex db IIC Gb / Ex eb IIC Gb / Ex ta IIIC Da
Protection: IP65 / IP66
Temperature Range: -60°C to 95°C
Material: Nickel Plated Brass (Marine Grade)
​​​​​​

Quick Links

NPT Nickel Hex
Silver
33.0
30.0
¾" / 0.75 NPT
20.5

In stock

10

£9.76 Excl VAT
Unit Price: £9.7600 £11.71 Inc VAT
Unit Price: £11.7120

Qty
Minimum Order Qty 1
Increments 1

Product Wishlist & Compare Placeholder

Delivery available from £8.50

Available to select at checkout.



Quick Links




National Pipe Thread (NPT) Hazardous Hex Head Plugs in nickel plated brass (marine grade) are engineered to safely blank unused threaded entries in Hazardous Area, machines, devices, housings, panels and enclosures. Suitable for both temporary and permanent use, these plugs are IECEx and ATEX certified, offering compliance with international standards for safe installation.  National Pipe Thread (NPT) is a tapered thread and is not supplied with sealing washers, P66 protection against dust, dirt and water ingress is achieved. With a temperature rating of -60°C to +95°C, they deliver long lasting performance. Available in the NPT range ½" to 3", these plugs are ideal for industrial, petrochemical, marine and offshore applications.



Key Features

  • Nickel-plated brass (marine grade) for strength and corrosion resistance
  • Hex head design for quick spanner tightening
  • IECEx and ATEX certified for hazardous environments
  • Provides IP66/IP68 ingress protection with sealing gasket
  • Wide operating range: -60°C to +95°C (up to +160°C with high-temp gasket)
  • National Pipe Thread (NPT) range ½" to 3"
  • Suitable for blanking threaded or unthreaded holes (with locknut)





Technical Details

Equipment Protection Levels: IECEx: Ex db I Mb / Ex eb I Mb / Ex db IIC Gb / Ex eb IIC Gb / Ex ta IIIC Da / Ex nR IIC
ATEX: I M2 Ex db I Mb / Ex eb I Mb, II 2G 1D Ex db IIC Gb / Ex eb IIC Gb / Ex ta IIIC Da
Protection: IP65 / IP66
Temperature Range: -60°C to 95°C
Material: Nickel Plated Brass (Marine Grade)
​​​​​​

Information

Product Type: NPT Nickel Hex

Colour: Silver

A/C: 33.0

A/F: 30.0

Male Thread: ¾" / 0.75 NPT

Male Thread Length (L1): 20.5
