SKU: ES127-150

ES127-150 - Emperor Single Cable Cleat - 127 to 150mm OD

SKU: ES127-150

ES127-150 - Emperor Single Cable Cleat - 127 to 150mm OD

The Emperor range offers the ultimate protection against the harshest conditions, and its unique design means it can be quickly installed. Manufactured in Type 316L Stainless Steel, Available in multiple sizes with range-taking capability, to suit trefoil or single cables. To protect and cushion the cables during short circuit conditions, the cleat is supplied with an integral Low Smoke and Fume Polymeric liner and base pad. We recommend that the Emperor is fixed using either two 10mm bolts, or a single 12mm bolt. Alternative bolt recommendations on request.

  • Superior strength tensile strength
  • Excellent weathering and corrosion resistance
  • Excellent stiffness



    Standards: European Standard IEC 61914:2021Max Short-Circuit: 149kA 600mm Spacing 195kA 300mm Spacing 235kA 225mm SpacingTemperature Range: -40°C to 60°CMaterial: 316 Stainless Steel / Polymeric Liner/Base Pad

Quick Links

127.0
150.0
Silver

0

Please contact us for more information.

Contact us

This product is currently out of stock. Your item will be shipped when it is back in stock.

Qty
Minimum Order Qty 1
Increments 1

Product Wishlist & Compare Placeholder

Delivery available from £8.50

Available to select at checkout.



Quick Links




The Emperor range offers the ultimate protection against the harshest conditions, and its unique design means it can be quickly installed. Manufactured in Type 316L Stainless Steel, Available in multiple sizes with range-taking capability, to suit trefoil or single cables. To protect and cushion the cables during short circuit conditions, the cleat is supplied with an integral Low Smoke and Fume Polymeric liner and base pad. We recommend that the Emperor is fixed using either two 10mm bolts, or a single 12mm bolt. Alternative bolt recommendations on request.

  • Superior strength tensile strength
  • Excellent weathering and corrosion resistance
  • Excellent stiffness



    Standards: European Standard IEC 61914:2021Max Short-Circuit: 149kA 600mm Spacing 195kA 300mm Spacing 235kA 225mm SpacingTemperature Range: -40°C to 60°CMaterial: 316 Stainless Steel / Polymeric Liner/Base Pad

Information

Single Range Min: 127.0

Single Range Max: 150.0

Colour: Silver

Accessories

You might also need the following;

Explore our range of cable cleat accessories including single, double and trefoil fixing kits, pre-cut M10 threaded studs, and channel nuts. Each accessory ensures secure, reliable cleat installation for all cable management systems in industrial and commercial applications.

Questions & Answers

Cable cleats are tested to IEC 61914, which sets out performance guidelines for strength, impact resistance, UV stability and corrosion. While not mandatory, reputable manufacturers follow this standard to confirm product reliability and safety. Are your cable cleats tested to IEC 61914?

A cable clamp is a general purpose fastener, while a cable cleat is specifically tested and rated to retain cables under axial, lateral and torsional forces (especially during short circuits)

Yes - accessories like fixing kits, pre cut threaded rod and channel nuts help secure cleats properly to mounting surfaces. Using the right hardware improves strength, alignment and vibration resistance.
